VIRTUALIZATION GPU Passthrough in Proxmox: The Complete Guide 2026-02-09 · proxmox · gpu · passthrough

GPU Passthrough in Proxmox: The Complete Guide

Virtualization 2026-02-09 proxmox gpu passthrough virtualization

GPU passthrough lets a virtual machine directly access a physical GPU as if it were installed in a bare-metal system. The VM gets near-native GPU performance — not the watered-down, driver-emulated kind you get with virtual graphics adapters. This opens up use cases that were previously impossible in a virtualized home lab: hardware-accelerated Plex transcoding, AI/ML model training, gaming VMs, and CAD workstations.

Proxmox VE supports GPU passthrough using VFIO (Virtual Function I/O), which binds the GPU to a special driver that hands control to the VM. The concept is simple. The execution has historically been painful, full of cryptic kernel parameters, IOMMU group headaches, and vendor-specific quirks. This guide walks through the process on modern Proxmox (8.x) with both NVIDIA and AMD GPUs, covering the things that actually trip people up.

Prerequisites

Before you start, verify you have what you need:

Hardware requirements:

The critical constraint: When you pass a GPU through to a VM, the host can no longer use it. If your CPU has integrated graphics (most Intel desktop CPUs, AMD APUs), the host can use the iGPU while the VM gets the discrete GPU. If you're using a Xeon or Ryzen without integrated graphics, you'll need to manage the host headlessly via the web UI or SSH.

Software requirements:

Step 1: Enable IOMMU in BIOS

IOMMU (Input/Output Memory Management Unit) is the hardware feature that makes passthrough possible. It creates isolated memory spaces for devices, allowing them to be safely assigned to VMs.

Reboot into your BIOS/UEFI settings and look for:

Intel systems:

AMD systems:

The exact menu location varies by motherboard manufacturer. Check under "Advanced," "CPU Configuration," "Northbridge Configuration," or "Security."

Some additional BIOS settings that help:

Step 2: Configure the Proxmox Host

Enable IOMMU in the Bootloader

Edit the GRUB configuration:

nano /etc/default/grub

Find the line starting with GRUB_CMDLINE_LINUX_DEFAULT and add the IOMMU parameters:

For Intel CPUs:

GRUB_CMDLINE_LINUX_DEFAULT="quiet intel_iommu=on iommu=pt"

For AMD CPUs:

GRUB_CMDLINE_LINUX_DEFAULT="quiet amd_iommu=on iommu=pt"

The iommu=pt (passthrough) flag improves performance by only applying IOMMU to devices actually being passed through, rather than all devices.

Update GRUB:

update-grub

If using systemd-boot (some Proxmox installs, especially ZFS root):

nano /etc/kernel/cmdline

Add to the existing line:

intel_iommu=on iommu=pt

Or for AMD:

amd_iommu=on iommu=pt

Update the boot entry:

proxmox-boot-tool refresh

Load VFIO Modules

Add the VFIO kernel modules to load at boot:

nano /etc/modules

Add these lines:

vfio
vfio_iommu_type1
vfio_pci

Note: In newer kernels (6.2+), vfio_virqfd has been merged into the vfio module. You don't need to add it separately.

Reboot and Verify

reboot

After reboot, verify IOMMU is active:

dmesg | grep -e DMAR -e IOMMU

You should see messages like:

DMAR: IOMMU enabled

Or for AMD:

AMD-Vi: AMD IOMMUv2 loaded

Verify VFIO modules are loaded:

lsmod | grep vfio

You should see vfio_pci, vfio_iommu_type1, and vfio.

Step 3: Check IOMMU Groups

IOMMU groups are the fundamental unit of device isolation. You can only pass through an entire IOMMU group to a VM — not individual devices within a group. If your GPU shares an IOMMU group with your SATA controller or network card, you'd have to pass all of them or none.

List your IOMMU groups:

#!/bin/bash
shopt -s nullglob
for g in $(find /sys/kernel/iommu_groups/* -maxdepth 0 -type d | sort -V); do
    echo "IOMMU Group ${g##*/}:"
    for d in $g/devices/*; do
        echo -e "\t$(lspci -nns ${d##*/})"
    done;
done;

Save this as a script and run it:

chmod +x iommu-groups.sh
./iommu-groups.sh

What you want to see: Your GPU and its audio device in their own IOMMU group, separate from everything else.

IOMMU Group 14:
    01:00.0 VGA compatible controller [0300]: NVIDIA Corporation GA106 [GeForce RTX 3060] [10de:2503] (rev a1)
    01:00.1 Audio device [0403]: NVIDIA Corporation GA106 High Definition Audio Controller [10de:228e] (rev a1)

What's a problem: Your GPU grouped with other devices.

IOMMU Group 1:
    00:01.0 PCI bridge [0604]: Intel Corporation ...
    01:00.0 VGA compatible controller [0300]: NVIDIA Corporation ...
    01:00.1 Audio device [0403]: NVIDIA Corporation ...
    02:00.0 Ethernet controller [0200]: Intel Corporation ...

Dealing with Bad IOMMU Groups

If your GPU is lumped with other devices, your options are:

  1. ACS override patch. An unofficial kernel patch that forces devices into separate groups. It works but reduces security isolation. Proxmox's pve-kernel supports it with a kernel parameter:

    pcie_acs_override=downstream,multifunction

    Add this to your GRUB or systemd-boot cmdline. Use as a last resort.

  2. Different PCIe slot. Try moving the GPU to a different slot. Some slots have better IOMMU grouping than others.

  3. Different motherboard. Enterprise and server motherboards generally have better IOMMU group isolation. Consumer boards are hit-or-miss.

  4. BIOS update. Some manufacturers fix IOMMU grouping in BIOS updates.

Step 4: Bind the GPU to VFIO

You need to prevent the host from loading a display driver for the GPU and instead bind it to the VFIO driver.

Find Your GPU's Device IDs

lspci -nn | grep -i nvidia
# or
lspci -nn | grep -i amd

Output example:

01:00.0 VGA compatible controller [0300]: NVIDIA Corporation GA106 [10de:2503] (rev a1)
01:00.1 Audio device [0403]: NVIDIA Corporation GA106 Audio [10de:228e] (rev a1)

The IDs are the vendor:device pairs in brackets: 10de:2503 and 10de:228e.

Configure VFIO to Claim the GPU

nano /etc/modprobe.d/vfio.conf

options vfio-pci ids=10de:2503,10de:228e disable_vga=1

Include both the GPU and its audio controller IDs.

Blacklist the Host GPU Drivers

Prevent the host from trying to use the GPU:

nano /etc/modprobe.d/blacklist.conf

For NVIDIA:

blacklist nouveau
blacklist nvidia
blacklist nvidiafb
blacklist nvidia_drm

For AMD:

blacklist amdgpu
blacklist radeon

Update initramfs

update-initramfs -u -k all

Reboot and Verify

reboot

Check that VFIO claimed the GPU:

lspci -nnk -s 01:00

You should see Kernel driver in use: vfio-pci for both the GPU and audio device:

01:00.0 VGA compatible controller [0300]: NVIDIA Corporation GA106 [10de:2503]
    Kernel driver in use: vfio-pci
01:00.1 Audio device [0403]: NVIDIA Corporation GA106 Audio [10de:228e]
    Kernel driver in use: vfio-pci

If you see nouveau, nvidia, amdgpu, or radeon instead, the blacklist didn't work. Double-check your config and regenerate initramfs.

Step 5: Configure the VM

Create the VM in Proxmox

Create a VM through the web UI with these settings:

Important for Windows VMs: Download the VirtIO ISO from the Fedora project and attach it as a second CD-ROM. You'll need the VirtIO drivers during Windows installation for disk and network access.

Add the GPU to the VM

In the Proxmox web UI:

  1. Select your VM > Hardware > Add > PCI Device
  2. Select your GPU (e.g., 01:00.0)
  3. Check these options:
    • All Functions: Yes (passes the GPU and its audio device together)
    • Primary GPU: Yes (if this is the VM's only display output)
    • ROM-Bar: Yes
    • PCI-Express: Yes

Alternatively, edit the VM config directly:

nano /etc/pve/qemu-server/YOUR_VMID.conf

Add:

hostpci0: 0000:01:00,pcie=1,x-vga=1
machine: q35
bios: ovmf
cpu: host

The x-vga=1 flag tells QEMU this is the primary display. If you're passing a second GPU for compute only (not display), omit x-vga=1.

Remove the Default Display

Once the physical GPU is passed through as the primary display, remove or disable the virtual display:

You'll get display output on the physical monitor connected to the passed-through GPU. Console access in the Proxmox UI will no longer show the VM's screen — use the physical display, RDP, or VNC instead.

NVIDIA-Specific Considerations

NVIDIA GPUs have quirks with passthrough that you need to handle.

The NVIDIA Code 43 Problem

Historically, NVIDIA's consumer (GeForce) drivers detected they were running in a VM and threw a "Code 43" error, refusing to work. This was NVIDIA's way of pushing people toward the much more expensive Quadro/Tesla cards for virtualization.

Good news: As of driver version 465+ (2021), NVIDIA removed this restriction for most GeForce cards. If you're running modern drivers, Code 43 usually isn't an issue. However, if you hit it:

Add to your VM config:

cpu: host,hidden=1,flags=+pcid
args: -cpu 'host,+kvm_pv_unhalt,+kvm_pv_eoi,hv_vendor_id=proxmox,kvm=off'

The hidden=1 and kvm=off flags hide the VM from NVIDIA's driver detection. The hv_vendor_id provides a fake Hyper-V vendor ID.

NVIDIA vGPU vs. Passthrough

Full passthrough dedicates the entire GPU to one VM. If you want to share an NVIDIA GPU between multiple VMs, you need vGPU — which requires a supported datacenter GPU (A-series, L-series) and an NVIDIA vGPU license.

For home labs, full passthrough is the practical choice. Consumer GeForce cards don't support vGPU, and the licensing cost for supported cards makes it impractical unless you're running a serious AI/ML setup.

GPU Reset Issues

Some NVIDIA GPUs (particularly older Pascal/Turing cards) have issues where the GPU won't reset properly after a VM shutdown. The GPU gets stuck in a bad state, and the only way to recover is to reboot the Proxmox host.

Workarounds:

  1. Vendor-reset module. A kernel module that handles GPU reset for problematic cards:

    apt install pve-headers-$(uname -r)
apt install git dkms
git clone https://github.com/gnif/vendor-reset.git
cd vendor-reset
dkms install .
echo "vendor-reset" >> /etc/modules
update-initramfs -u

  2. Don't shut down, hibernate instead. Some users avoid the problem by always hibernating the VM instead of shutting it down.

  3. Use a newer GPU. Ampere (RTX 30-series) and later cards generally handle resets correctly.

AMD-Specific Considerations

AMD GPUs are generally easier for passthrough. AMD doesn't restrict virtualization on consumer cards, and the open-source driver stack means fewer compatibility surprises.

AMD GPU Reset

AMD GPUs also had reset issues historically, especially Polaris (RX 400/500 series) and early Navi (RX 5000 series). The vendor-reset module mentioned above also supports AMD cards with reset problems.

RDNA2 (RX 6000 series) and later generally reset cleanly.

AMD Driver Considerations

AMD APU Passthrough

If your CPU is an AMD APU (like the 5600G or 7600G), the integrated GPU uses the amdgpu driver. You can potentially pass this through to a VM, but it's tricky because the iGPU shares an IOMMU group with other platform devices. If you're using the iGPU for passthrough, you'll need a discrete GPU or headless operation for the host.

Use Cases

Plex/Jellyfin Hardware Transcoding

Passing a GPU to a Plex or Jellyfin VM enables hardware-accelerated transcoding. A single NVIDIA GPU can handle 10-20 simultaneous 1080p transcodes, compared to 1-3 with CPU-only.

For Plex, even a low-end NVIDIA GPU (GTX 1650, RTX 3050) is massively faster than CPU transcoding. Intel Quick Sync (via iGPU) is actually better value for pure transcoding — you don't need passthrough for that, just share the iGPU device. But if you need NVENC specifically or are already passing a GPU for other reasons, it works great.

Note: For Docker-based media servers, consider using the GPU as a shared device (not full passthrough) so the host and containers can use it simultaneously:

# Docker Compose with GPU access (no passthrough needed)
services:
  jellyfin:
    devices:
      - /dev/dri:/dev/dri    # Intel iGPU
    # Or for NVIDIA:
    deploy:
      resources:
        reservations:
          devices:
            - capabilities: [gpu]

Full passthrough is only needed when the GPU must be exclusively owned by a VM.

AI/ML Training and Inference

GPU passthrough gives a VM direct access to CUDA cores (NVIDIA) or ROCm compute (AMD). This is the preferred setup for home AI/ML work because:

A popular setup: Proxmox host with an NVIDIA RTX card passed through to an Ubuntu VM running Jupyter Lab with PyTorch. The VM can be snapshotted, backed up, and restored without affecting the host.

Windows Gaming VM

Run Windows as a VM with a dedicated GPU for gaming. Combined with USB passthrough for a keyboard, mouse, and controller, you get a gaming setup that's nearly indistinguishable from bare metal.

Add to the VM config for USB passthrough:

usb0: host=1234:5678    # Keyboard vendor:product ID
usb1: host=abcd:ef01    # Mouse vendor:product ID

Find USB device IDs with:

lsusb

For the best gaming experience:

# In VM config
cpu: host,hidden=1
cores: 8
numa: 1
hostpci0: 0000:01:00,pcie=1,x-vga=1

# CPU pinning (example for cores 8-15)
affinity: 8-15

Expect 95-98% of bare metal performance with proper configuration.

Multi-Seat Workstations

With two GPUs and GPU passthrough, one physical computer can serve two independent users. Each user gets their own VM with a dedicated GPU, monitor, keyboard, and mouse. Useful for households that need two workstations but only have budget/space for one powerful machine.

Troubleshooting

Black Screen on VM Start

VM Starts but No GPU in Device Manager (Windows)

Performance Is Poor

GPU Won't Release After VM Shutdown

Host Crashes When Starting VM

Summary

GPU passthrough in Proxmox is a powerful capability that turns your home lab into a flexible compute platform. The setup process has gotten significantly easier over the years — IOMMU support is standard on modern hardware, VFIO is well-integrated in the kernel, and vendor-specific headaches (NVIDIA Code 43, AMD reset bugs) are largely resolved on current-generation hardware.

The steps, in summary:

  1. Enable IOMMU in BIOS (VT-d for Intel, AMD-Vi for AMD)
  2. Add kernel parameters (intel_iommu=on iommu=pt or amd_iommu=on iommu=pt)
  3. Load VFIO modules
  4. Verify IOMMU groups (GPU should be isolated)
  5. Bind the GPU to vfio-pci
  6. Blacklist host GPU drivers
  7. Create a q35/OVMF VM and add the GPU as a PCI device

If you have decent hardware from the last few years and a supported GPU, the whole process takes about 30 minutes. The payoff — native GPU performance in a virtual machine — is worth every minute of configuration.
